What Is Dry Running and Why Is It Important?

In industrial facilities, one of the most common and costly causes of pump failure is dry running, which occurs when a pump operates without liquid. When the liquid level inside a tank or vessel falls below a critical threshold, the pump begins to run without fluid, leading to excessive heat build-up, damage to the mechanical seals, and, in a short period of time, complete pump motor failure.

To prevent this risk, the liquid level inside the tank must be monitored continuously and reliably. Developed by PNOTOL, the LFS Series Level Switches are specifically designed for this purpose, offering a simple, durable, and maintenance-free level detection solution.

The cost of dry running extends far beyond replacing a damaged pump. Unexpected failures can result in production downtime, unplanned maintenance expenses, and, in some cases, secondary issues that compromise process safety. For this reason, investing in reliable level monitoring should be regarded not merely as equipment protection but as an essential part of a comprehensive operational safety strategy.

Operating Principle of the LFS Series Level Switches

The LFS Series operates using float switch technology. As the liquid level rises or falls, the float moves accordingly. Once it reaches a predefined switching point, the internal mechanism opens or closes an electrical contact.

This straightforward yet highly reliable design enables years of uninterrupted operation without requiring an external power supply or complex electronic circuitry.

The switching point is predetermined according to the tank geometry and the equipment requiring protection. As a result, the system provides an early warning before the liquid level reaches a critical point, sending a signal either to the automation system or directly to the pump control circuit.

Advantages of the LFS Series in Pump Protection Systems

One of the key advantages of the LFS Series is its ability to integrate directly into pump protection circuits. When the minimum liquid level is detected, the pump is automatically shut down, preventing mechanical damage caused by dry running. This not only extends the service life of the equipment but also reduces production losses resulting from unexpected downtime.

Its compact housing allows for easy installation even in tanks with limited mounting space. In addition, corrosion-resistant material options make the LFS Series suitable for applications involving chemicals or other aggressive liquids.

Differences Between Minimum and Maximum Level Detection Models

The minimum level detection model within the LFS Series is designed to protect pumps against dry running. When the liquid level inside the tank falls below the critical minimum level, the switch activates and triggers the protection system. This model is particularly well suited to feed lines where there is a risk of the pump running dry.

The maximum level detection model, on the other hand, operates in the opposite scenario. When the liquid reaches the predefined upper limit, the switch activates to prevent tank overflow. In storage tanks requiring automatic filling control, using both models together provides comprehensive level protection.

Installation and Maintenance Recommendations for Industrial Applications

When installing an LFS Series Level Switch, the most important consideration is ensuring that the float has sufficient space to move freely inside the tank. Contact between the float and the tank wall or surrounding equipment may result in inaccurate switching.

Although the device’s mechanical design requires very little maintenance, it is recommended that the float surface be inspected and cleaned periodically, particularly in applications involving liquids containing high levels of suspended particles. This simple maintenance routine helps maintain long-term accuracy and reliable operation.

Key Considerations When Selecting the Right Level Switch

When choosing a level switch, it is essential to consider the characteristics of the application, including the type of liquid, operating temperature range, and tank pressure. Although the LFS Series is designed to operate reliably across a wide range of temperatures and pressures, selecting the correct process connection and material specification remains critical, particularly for specialised applications.

At PNOTOL, we help you identify the most suitable level switch for your operational requirements. Contact our technical team for further information about our product range and for tailored recommendations designed specifically for your application.
